Pilot Rock RJ Thomas Mfg. Co.

Frame Kit - Kid's Rectangular Picnic Table - UTK Series

Please make the following configuration choices:

Frame Finish

Select the finish you want on the frames.

Frame Kit Size Options

Buy just the frame kit. Then provide your own top/seat/slat material from a local source.

($135.00)
($135.00)
($135.00)
($200.00)
($135.00)
($217.00)

Model UTK Picnic Table Frame Kits are designed for most public applications.  Children can be hard on furniture.  You need picnic tables that are built to take it!  These tables use the same construction as our standard sized picnic tables.  They have been proportionally scaled to fit children up to 10 or 11 years old.

Specifications:

Model UTK Picnic Table Frame Kits feature our non-tip, non-trip, walk through design.  The table won’t tip even if all persons sit on one side.  Easy walk through access.  “Skid” design permits movement without damage to turf.  Model UT Picnic Tables offer 22” nom. table height; 12” nom. seat height.

FRAME KIT: All welded 1-5/8" OD steel pipe end frames (1.660" OD, 11 ga. wall, 1-1/4" ID nom. pipe specifications).  Top/seat mounting brackets are 2" x 2" x 10 ga. die formed steel angles.  Frames are supported by diagonal braces of 1-5/16" OD steel pipe attached to steel center channel.  All 3/8" dia. galvanized carriage bolt fasteners.

FINISH: Standard finish: hot dip galvanized after fabrication.  Or choose a powder coat finish (in place of galvanized finish) in your color choice.
