Pilot Rock RJ Thomas Mfg. Co.

FSW-30 Campfire Ring

Please make the following configuration choices:

Campfire Ring Side Heights

Choose your campfire ring side height.

($155.00)
($187.00)
($206.00)

Campfire Ring Anchor Systems

Choose your desired anchor system configuration

($20.00)
($17.00)

Campfire Ring Shelf Options

($17.00)

Campfire Ring Heat Shields

Select an optional heat shield for your campfire ring. NOT AVAILABLE on rings less than 11 inches tall.

($66.00)

The FSW Series Campfire Rings combine a single level swivel cooking grate with our flanged fire ring.  The 300 sq. inch single level Swivel Grate will move 180 degrees – from over the fire to completely out of the fire ring – for easy fire building and serving.  The handle is never over the fire.

Fire ring is rolled from a 3/16" thick steel plate with an integral formed 1" wide flange around top edge.  This flange provides extra strength against heat warpage and eliminates a vertical edge.  Draft holes are provided for fire ventilation.

Model FSW-30 Series Campfire Ring features a 30” inside diameter and is available in three different side heights of 7-3/8”, 9”, and 11-3/8”.

FSW Series fire rings include tip back anchor pins (/TB) to keep the campfire ring secured in one place, but allow the fire ring to tip up for easy clean out.  These pins must be set in concrete. The firering can be tipped up.

The cooking grate is a single, welded component using ½-inch dia. steel bars, mounted on a 2-3/8” OD steel tube allowing it to swivel 180 degrees.  The operator handle includes a 1/8” x ½” flat bar coiled spring grip.  All grate bars are welded on both sides.  All fire rings are finished with high temp non-toxic black enamel paint.

OPTIONAL Anchor Systems:
Angle Spade Anchors (/AL) are 3 spades attached around the firering and buried in the ground. The firering cannot be tipped up.

Tip Back Spade Anchors (/TA) are 2 spades at the rear hinge point and buried in the ground. The firering can be tipped up.

Tip Back-Bolt Down Anchor Bracket (/TB-BD): this steel bracket will anchor your firering already equipped with tip back tabs (FA-30, FS-30, FSW-30, FSW/SL-30, FX-30 and L-32 series only) to an existing concrete surface. The firering will be able to tip up. The TB-BD bracket includes fasteners to attach it to the firering tabs. It does NOT include the (3) ½-inch diameter anchor bolts.
(Note: We do not recommend installation on top of concrete. But if you choose to install your firering on concrete the TB-BD anchor will secure the firering onto your concrete base.)

OPTIONAL: Model S-5 Bolt-on Utility Shelf

 California's Proposition 65.
