Pilot Rock RJ Thomas Mfg. Co.

FSWS-30 Accessible Stainless Steel Campfire Ring

Please make the following configuration choices:

Campfire Ring Stainless Steel Side Heights

Choose your stainless steel campfire ring side height.

($464.00)
($575.00)

Campfire Ring Anchor Systems

Choose your desired anchor system configuration

($20.00)

Campfire Ring Shelf Options

($17.00)

The FSWS Series Campfire Ring is rolled using 11 ga. (1/8” thick) stainless steel with a 1” roll formed top flange for additional strength and safety.  Draft holes are provided for ventilation. The ring is not painted.

The FSWS-30 accessible firering is available in two side heights: 17 and 23 inches. See chart below.

Standard: 300 sq. inch single level swivel cooking grate, will move 180 degrees – from over the fire to completely out of the firering – for easy fire building and serving. The handle is never over the fire. Some installation required.

This swivel grate meets the ADA guidelines for reach and operability: one hand operation requiring less than 5 lbs. of force to move.

Swivel cooking grate is a single welded component using ½-inch dia. black steel bars, mounted on a 2-3/8-inch OD steel tube allowing it to swivel 180 degrees. Operator handle includes a 1/8-in. x ½-in. flat bar coiled spring grip. All grate bars are welded on both sides. Cooking grate components are finished with high temp non toxic black enamel paint.

Standard: three black steel pin anchors (PA) to secure the firering on site, into concrete footings (ring does not tip up).

OPTIONAL: three black steel bolt on spade anchors (AL) to secure ring on site, buried in ground (ring does not tip up).

OPTIONAL: S5 bolt-on utility shelf, black steel.

Stainless Steel Campfire Rings FSWS Series Size Chart

 California's Proposition 65.
