Pilot Rock RJ Thomas Mfg. Co.

Frame Only Kit For Accessible Bench - B110C & B111C Series

Please make the following configuration choices:

Installation / Mount

Choose how you plan to install the product.

Frame Finish

Select the finish you want on the frames.

Frame Kit Size Options

Buy just the frame kit. Then provide your own top/seat/slat material from a local source.


Series Overview

The Accessible Bench Frame Kit incorporates the full-length grab bar across the back of the bench to enhance access and transfer to or from this bench.  This is a unique adaptation of interior accessibility features to exterior furniture.


FRAME KIT: All welded steel frame fabrication: seat/back support channel is die-formed from 1/8" thick (11 ga.) steel, frame post and portable/surface mount foot are made using 2-3/8" OD steel pipe.

FINISH: Hot dip galvanized after fabrication for maximum protection from the elements.  Or, select a powder coat finish in your color choice.

SURFACE MOUNT: Model B110C Features: 6 ft. long, portable/surface mount frames, grab bar 35" high, seat width 20", seat height 18-1/2" (nom. dimensions), includes 9/16" dia. anchor holes in foot (surface anchors are not included).  Use Model ANC3-6 Anchor Kit.

EMBEDDED MOUNT: Model B111C Features: 6 ft. long, embedded frame post installation, grab bar 35" high, seat width 20", seat height 18-1/2" (nom. dimensions).

SEAT & BACK MATERIALS: Frame kit only – does not include seat/back boards. Use your own 2" x 4" (nom.) lumber, or 100% recycled plastic boards.
